Product Description
| product | Paragon LED Module |
| Model No | CBHT-042-30135-120V-30-G02 |
| COB Holder Model No | GHH36135AC |
|
LED Type |
COB LED |
| No LED chips | 42 |
| Wattage | 4WÂ |
| Voltage | 120 VAC |
| Power Factor | PF>0.98 |
| Luminous Intensity | 280 lumens |
| Color Temperature | 3000K (Warm White) |
| Dimmable | Yes |
| Rendering Index | CRI>90 |
| IP Rating | IP20 (Indoor rated) |
| COB Holder Dimensions | ∅35.7mm (1.4 in) x H11.60mm (0.45 in) |
| COB Module Outer Diameter | ∅27 mm (1.06 in) |
| Operating Temperature | -40 ~ +105℃ |
| Storage Temperature | -40 ~ +105℃ |
| Assembly process Temperature | <300℃ |
| Solder joint point | <105℃ |
| Dielectric Breakdown Voltage of Thermal Pad | >4KV |
| Included Content | COB Module, COB LED array Holder, Thermal Pad |
| Certifications |  |
The CBHT-42-30135-120V-30-G02 is a Paragon LED Module that uses a COB LED technology with 42 LED chips, producing a warm white light with a color temperature of 3000K. It has a low power consumption of 4W and operates at a voltage of 120V AC. The module has a high power factor of PF>0.98 and a luminous intensity of 280 lumens with a high color rendering index of CRI>90.
The module comes with a GHH36135AC LED holder and a polycarbonate lampshade that can be easily attached or detached. The COB holder is designed to mechanically secure, electrically connect and press the module to an aluminum heat sink. It also includes a silicone grease thermal pad that helps in better heat dissipation and increases the lifespan of the module.
Features:
- Power consumption: 4W
- Operating voltage: 120V AC
- Power factor: PF>0.98
- Luminous intensity: 280 lumens
- Color rendering index: CRI>90
- Accessories: GHH36135AC LED holder, polycarbonate lampshade
- COB holder: Secures, connects and presses module to heat sink
- Thermal pad: Helps in heat dissipation and increases lifespan
- Location suitability: Damp locations, IP20 rating
- Grounding recommendation: While designing lamps
- Certification: UL certified
- Application: Suitable for use in a wide range of luminaires
